Cooler Master MWE 550 V3 ATX 3.1 80 Plus Bronze 550 Watt  Non Modular Power Supply Unit ( MPE-5501-ACABW-3BIN )

Cooler Master

Cooler Master MWE 550 V3 ATX 3.1 80 Plus Bronze 550 Watt  Non Modular Power Supply Unit ( MPE-5501-ACABW-3BIN )

  • ATX 3.1 support
  • High temperature resilience
  • Quiet HDB fan
  • 80 Plus Bronze certified efficiency
  • Embossed cable
  • 5-year warranty

4,090.00

Compare

Cooler Master MWE 550 V3 ATX 3.1 80 Plus Bronze 550 Watt  Non Modular Power Supply Unit ( MPE-5501-ACABW-3BIN )

Introducing the MWE Bronze V3 230V, the evolutionary next step in Cooler Master power and the ATX 3.1 upgrade to our MWE Bronze V2 PSU. With features such as 80 Plus Bronze efficiency, a DC-to-DC + LLC circuit design, and a quiet HDB fan cooling, the V3 provides valuable performance in multiple dimensions. Several changes and additions improve the overall user experience. Together, these design choices deliver an advanced PSU that is highly efficient and reliable. With an embossed cable, exceptional temperature resilience and a 5-year warranty, the MWE Bronze V3 will evolve your machine.

Quiet HDB fan: A hydrodynamic bearing fan delivers long-lasting quiet and effective cooling.

80 Plus Bronze efficiency certification: This unit is certified to achieve more than 88% efficiency at typical loads in a 230V test.

ATX 3.1 support: Compliant with ATX 3.1 to fully support a peak power 1.5 times higher than the rated maximum wattage, this unit is ideal for use with the 40 series GPUs.

Specifications:

 Model Number  MPE-5501-ACABW-3BIN
 ATX Version  ATX 12V Ver. 3.1
 PFC  Active PFC
 Input Voltage  200-240V
 Input Current  5A
 Input Frequency  50-60Hz
 Dimensions (L x W x H)  140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
 Fan Size  120mm
 Fan Bearing  HDB
 Efficiency  >88% @ Typical Load
 80 PLUS Rating  80 PLUS Bronze EU 230V
 ErP 2014 Lot 3  Yes
 Operating Temperature  0-40°C
 Power Good Signal  100 – 150 ms
 Hold Up Time  >16ms
 MTBF  >100,000 Hours
 Protections  UVP / OVP / OPP / OTP / SCP
 Regulatory  TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region’s request.)
 Series  MWE Bronze Series
 Category  500 to 750W
 Modular  Non Modular
 80 Plus  Bronze
 Form Factor  ATX
 Watts  550W
 ATX 24 Pin Connectors  1
 EPS 8 Pin / 4+4 Pin Connectors 2
 SATA Connectors  6
 Peripheral 4 Pin Connectors  3
 PCI-e 6+2 Pin Connectors  2
 Warranty  5 Years
