Arctic Liquid Freezer III 240 A-RGB Liquid Multi Compatible All-in-One CPU Water Cooler With 2 x 120mm P12 PWM PST A-RGB Fans ( ACFRE00142A )

General Specifications

• Warranty :- 6 Years
• TIM :- MX-6 (0.8 g)
• Operating Ambient Temperature :- 0—40 °C
• PI | NNPI :- 308 | 230
• LED Connector :- 3-Pin A-RGB Connector
• All-In-One Connector :- 4-Pin PWM Connector
• Splitt Connector :- 3x 4-Pin PWM Connector
• Weight :- 1490 g

Compatibillity

• Intel :- 1851, 1700
• AMD :- AM5, AM4

Pump Specifications

• Pump :- 800—2800 rpm (PWM controlled)
• Current | Voltage :- 35 A | 12 V DC
• Cold Plate :- Copper, Micro Skived Fins
• Tube Length :- 450 mm
• Tube Diameter :- Outer: 12.4 mm
• Inner: 6.0 mm

Radiator Specifications

• Material :- Aluminium
• Dimensions :- 277 (L) x 120 (W) x 38 (H) mm
• VRM Modul Specifications :-
• VRM Fan :- 400—2500 rpm (PWM controlled)
• Current | Voltage :- 05 A | 12 V DC
• LEDs :- 12x A-RGB LEDs
• Current | Voltage :- 40 A | 5 V DC

Fan Specifications

• General :- 2x P12 PWM PST A-RGB
• Speed :- 200—2000 rpm
• Air Flow :- 82 cfm | 82.91 m³/h
• Static Pressure :- 85 mmH₂O
• Bearing :- Fluid Dynamic Bearing
• Current | Voltage :- 11 A | 12 V DC
• Cable Lenght :- 40 mm
• Connector :- 4-Pin PWM Connector

RGB Specifications

• LEDs :- 12x A-RGB LEDs
• Current | Voltage :- 40 V | 5 V DC
• Cable Lenght :- 40 mm + 80 mm Splitter Cable
• Connector :- 3-Pin A-RGB Connector + 3-Pin Plug

Packaging

•  Width: 171 mm
•  Height: 142 mm
•  Length: 294 mm
• Weight: 1.925 kg
